H805VDMF Board Description
The H805VDMF is a 48-port VDSL2 over POTS service board. It works with the VDSL transceiver unit-remote end (VTU-R) through the VDSL port to support the VDSL2 service.
Feature and Specifications
Please refer to "48-Channel VDSL2 Service Board Comparison".
Parameters
Please refer to "Power Consumption and Maximum Frame Size of Boards".
Working Principle
Figure 1 Working principle of the H805VDMF board
| Indicates the channel of control signal. |
| Indicates the channel of service signal. |
| Indicates the control module which loads the board software, controls the running of the board, and manages the board. |
| Indicates the service modules and boards which the service signals pass through. |
| Indicates the channel of power or clock signal. |
| The power module supplies power to each functional module of the board. The clock module provides clock signals for each functional module of the board. |
Front Panel Port
NOTICE:
When cables from the xDSL ports are routed to an outdoor environment or the user side, the MDF must be installed with a protective unit.
Indicator
Indicator | Name | Status | Meaning |
RUN ALM | Running status indicator | Green: blinks every 1s | The board works in the normal state |
Green: blinks every 0.25s | The board is starting up | ||
Orange: blinks | A high-temperature alarm is generated | ||
Red: on | The board is faulty | ||
BSY | Port status indicator | Green: on | At least one service port is activated |
Green: off | No service port is activated |
Pin Assignments
For pin assignment of the xDSL0 port, see Table 1; For pin assignment of the xDSL1 port,
