H801VSPHA 64-port VDSL2 over ISDN splitter board H801X1CA H801X2CS H801M2XA H801SPUA H801SCUK MA5600 MA5800

H901CIUA Board Description

The H901CIUA board is a general interface board. It provides the input and output clock source for the system and supports functions such as input and output of alarm digital parameters.

Feature and Specifications

The H901CIUA board supports the following functions:

Seven inputs of alarm digital parameters and one output of digital controlling parameters

Two inputs of 2 Mbit/s or 2 MHz BITS clock signals

Two inputs of 1PPS+TOD time signals

One output of 2 Mbit/s or 2 MHz clock signals

One output of 1PPS+TOD time signals

External monitoring Ethernet port to transparently transmit monitored data

RS485 port to transparently transmit data

Multiple working modes, such as tracing, holdover, and free-run

Parameters

Board Parameter

You can query power consumption, weight, maximum frame size, and normal operating temperature of all boards.

Table 1 lists the power consumption, weight, and maximum frame size of boards.

The operating temperature of H901XSED and H901TWED is -40°C to +55°C (in MA5800–X17/X15/X7) or -40°C to +65°C (in MA5800–X2) and the lowest board startup temperature is -25°C. The operating temperature of other boards is -40°C to +65°C and the lowest board startup temperature is -25°C.

 NOTE:

The power consumption of a board is calculated based on the following conditions:

Operating voltage: -53.5 V DC.

Ambient temperature: 25°C.

Static power consumption: All ports do not carry any loads and optical modules are not installed on optical ports.

Maximum power consumption: All ports fully carry loads.

The board power consumption slightly varies with the power module configured for the board and discreteness of components.

Table 1 Power consumption and maximum frame size of boards
