Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | OLT |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Product Name: | Ma5800 | Brand: | Huawei |
|---|---|---|---|
| Model: | MA5800-X2 | Warranty: | 1 Year |
| Port: | Shenzhen |
Ultra-broadband optical networking supports Fixed Mobile Convergence (FMC) and SDN-based smart services
| Item | MA5800-X17 | MA5800-X15 | MA5800-X7 | MA5800-X2 |
| Dimensions (W x D x H) | 493 mm x 287 mm x 486 mm | 442 mm x 287 mm x 486 mm | 442 mm x 268.7 mm x 263.9 mm | 442 mm x 268.7 mm x 88.1 mm |
| Maximum Number of Ports in a Subrack | 272 x GPON/EPON | 240 x GPON/EPON | 112 x GPON/EPON | 32 x GPON/EPON |
| 816 x GE/FE | 720 x GE/FE | 336 x GE/FE | 96 x GE/FE | |
| 136 x 10G GPON/10G EPON | 120 x 10G GPON/10G EPON | 56 x 10G GPON/10G EPON | 16 x 10G GPON/10G EPON | |
| 136 x 10G GE | 120 x 10G GE | 56 x 10G GE | 16 x 10G GE | |
| 544 x E1 | 480 x E1 | 224 x E1 | 64 x E1 | |
| Switching Capacity of the System | 7 Tbit/s | 480 Gbit/s | ||
| Maximum Number of MAC Addresses | 262,143 | |||
| Maximum Number of ARP/Routing Entries | 64K | |||
| Ambient Temperature | -40°C to 65°C | |||
| Note: The MA5800 can start up at a lowest temperature of -25°C and run at -40°C. The 65°C temperature refers to the highest temperature measured at the air intake vent | ||||
| Working Voltage Range | -38.4V DC to -72V DC | DC power supply: | ||
| -38.4V to -72V | ||||
| AC power supply: | ||||
| 100V to 240V | ||||
| Layer 2 Features | VLAN + MAC forwarding, SVLAN + CVLAN forwarding, PPPoE+, and DHCP option82 | |||
| Layer 3 Features | Static route, RIP/RIPng, OSPF/OSPFv3, IS-IS, BGP/BGP4+, ARP, DHCP relay, and VRF | |||
| MPLS & PWE3 | MPLS LDP, MPLS RSVP-TE, MPLS OAM, MPLS BGP IP VPN, tunnel protection switching, TDM/ETH PWE3, and PW protection switching | |||
| IPv6 | IPv4/IPv6 dual stack, IPv6 L2 and L3 forwarding, and DHCPv6 relay | |||
| Multicast | IGMP v2/v3, IGMP proxy/snooping, MLD v1/v2, MLD Proxy/Snooping, and VLAN-based IPTV multicast | |||
| QoS | Traffic classification, priority processing, trTCM-based traffic policing, WRED, traffic shaping, HqoS, PQ/WRR/PQ + WRR, and ACL | |||
| System Reliability | GPON type B/type C protection, 10G GPON type B protection, BFD, ERPS (G.8032), MSTP, intra-board and inter-board LAG, In-Service Software Upgrade (ISSU) of the control board, 2 control boards and 2 power boards for redundancy protection, in-service board fault detection and rectification, and service overload control | |||
Return Material Authorization (RMA) Process
Standard Hardware Warranty Policy:
Original new sealed ZTE product: 1 Year
The Support Contacts:
If your ZTE products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
Cargo will be delivered within 1 day after payment arrived. Tracking Number will be offered once delivery done.
Uonel is one of the biggest Huawei Network Hardware distributor in china, founded in 2008. We are a global provider of netwotking products with more than 5000 customers.
We provide original new Huawei Routers,Switches,Firewalls,Wireless APs & controllers,OLTs,GPON modems,optical transceivers.Our company have more than $5million Huawei products in stock.
Most of our technical engineers had work exprience in Huawei company,we can provide network design&planning,configration,troubleshooting,maintenance and training service in world wide.
