1150 W AC PoE Power Module
Product Support
Table 1 lists the switch models supporting a 1150 W AC PoE power module.
Table 1 Product support for a 1150 W AC PoE power module
| Power Module Name | Product Support |
| W2PSA1150 | S5710-52C-PWR-EI, S5720-52X-PWR-SI-ACF, S5720-56C-PWR-HI-AC, S5710-108C-PWR-HI, S5720-56C-PWR-EI-AC1, S5730-68C-PWR-SI, S5730S-68C-PWR-EI S6720-32C-PWH-SI, S6720-52X-PWH-SI, S6720-56C-PWH-SI |
Appearance
Figure 1 Appearance of a 1150 W AC PoE power module (W2PSA1150)
Figure 2 shows a 1150 W AC PoE power module installed on a switch.
Figure 2 1150 W AC PoE power module on a switch
NOTE:
If a switch uses 1150 W power modules, it is recommended that the switch be installed in an 800 mm or deeper standard cabinet. If the switch is installed in a 600 mm deep cabinet, the rear door of the cabinet cannot be closed.
Functions
Table 2 describes the functions of a 1150 W AC PoE power module.
Table 2 Functions of a 1150 W AC PoE power module
| Function | Description |
| PoE power supply | Provides a maximum of 800 W PoE power. |
| Input protection | Provides protection against input overcurrent and input undervoltage. |
| Output protection | Provides protection against output overvoltage, output overcurrent, and output short-circuit. |
| Overtemperature protection | When the temperature of the power module exceeds a specified threshold (70°C), the power module stops supplying power. When the temperature falls into the normal range, the power module automatically resumes power supply. |
| Hot swap | Supported |
NOTE:
When a power module enters overtemperature protection state, take measures to lower the ambient temperature. The power module can automatically resume power supply when the temperature falls within the normal range.
Panel
Figure 3 Panel of a 1150 W AC PoE power module (W2PSA1150)
| 1. Captive screw | 2. Airflow flag (air out) | 3. Indicator | 4. Handle |
| 5. Fan | 6. Power switch | 7. AC power socket | 8. AC power cable locking strap |
Table 3 describes indicators on a 1150 W AC PoE power module panel.
Table 3 Description of indicators on a 1150 W AC PoE power module panel
| Indicator | Color | Description |
| STATUS | Green | Off: The AC power input is abnormal, for example, no AC input power, AC input overvoltage, or AC input undervoltage occurs. The AC power output is abnormal, for example, output undervoltage or overtemperature occurs. Steady on: The AC power input is in the normal range. Blinking: The AC power output is abnormal, for example, overvoltage, overcurrent, or short circuit occurs. |
Specifications
Table 4 lists the specifications of a 1150 W AC PoE power module.
Table 4 Technical specifications of a 1150 W AC PoE power module
| Item | Description |
| Dimensions (W x D x H) | 100.0 mm x 281.0 mm x 41.4 mm (3.9 in. x 11.1 in. x 1.63 in.) |
| Weight | < 1.6 kg (3.53 lb) |
| Rated input voltage | 100 V AC to 240 V AC, 50/60 Hz |
| Maximum input voltage | 90 V AC to 290 V AC, 45 Hz to 65 Hz |
| Input current | 10 A |
| Maximum output current | +12 V: 29.17 A -53.5 V: 14.95 A |
| Maximum output power | PoE: 800 W (220 V)/450 W (110 V) Total: 1150 W (220 V)/800 W (110 V) |
| Part number | 02130984 |
