Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | OLT |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Product Name: | UA5000 | Application: | Network |
|---|---|---|---|
| Type: | GPON ONT | Warranty: | 1 Year |
| Port: | Shenzhen |
UA5000 Multi-Service Access Platform
Four-in-one access unit provides integrated broadband and narrowband access services for enterprise networks, industrial automation, and service providers.
Flexible multi-service platform supports smooth evolution from Public Switched Telephone Network (PSTN) service to Next-Generation Networking (NGN), then to IP Multimedia Subsystem (IMS) and upstream Passive Optical Network (PON) networking.
The UA5000 provides high-quality narrowband voice services, broadband access, and superb quality IP telephony.
Shelf Types and applications of the shelves supported by the UA5000:
| Shelf Model | Type | Number of Slots for Service Boards/Total Slots |
| HABA | Rear-access maintenance shelf | 30/36 |
| HABD | Front-access maintenance shelf | 12/18 |
| HABF | Front-access slave shelf | 18/18 |
| HABL | Front-access maintenance shelf | 6/12 |
| HABM | Front-access maintenance shelf | 6/9 |
| configuration | F01D200 | F01D500 | F01D1000 | F01E200 | F01E400 |
| W×D×H(mm) | 1250×550×1200 | 1550×550×1650 | 1900×550×1650 | 1000×550×1200 | 1000×550×1200 |
| Frame configuration | 1 HABD | 1 HABD+1 HABF | HABD+HABF+HABD | HABL+HABM | HABD |
| POTS | 768 | 1920 | 2688 | 384 | 768 |
| ADSL | 384 | 960 | 1344 | 192 | 384 |
| POTS+ADSL | 384 | 960 | 1344 |
Return Material Authorization (RMA) Process
Standard Hardware Warranty Policy:
Original new sealed ZTE product: 1 Year
The Support Contacts:
If your ZTE products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
Cargo will be delivered within 1 day after payment arrived. Tracking Number will be offered once delivery done.
Uonel is one of the biggest Huawei Network Hardware distributor in china, founded in 2008. We are a global provider of netwotking products with more than 5000 customers.
We provide original new Huawei Routers,Switches,Firewalls,Wireless APs & controllers,OLTs,GPON modems,optical transceivers.Our company have more than $5million Huawei products in stock.
Most of our technical engineers had work exprience in Huawei company,we can provide network design&planning,configration,troubleshooting,maintenance and training service in world wide.
