LS-S5328C-EI-24S Overview
Huawei LS-S5328C-EI-24S is one of the Quidway S5300 series gigabit switches. The Quidway S5300 series gigabit switches (hereinafter referred to as the S5300s) are new generation Ethernet gigabit switches developed by Huawei to meet the requirements for high-bandwidth access and Ethernet multiservice convergence, providing powerful Ethernet functions for carriers and enterprise customers. Based on the new generation high-performance hardware and Huawei Versatile Routing Platform (VRP) software, the S5300 features large capacity and gigabit interfaces of high density, provides 10G uplinks, meeting customers' requirements for the 1G and 10G uplink devices of high density. The S5300 can meet the requirements of multiple scenarios such as service convergence on campus networks and intranets, the access to the IDC at a rate of 1000 Mbit/s, and the access to computers at a rate of 1000 Mbit/s on intranets. Huawei S5300 Series Switch S5328C-EI-24S Mainframe 24 100/1000 SFP, 4 Combo GE 10/100/1000 RJ-45),Chassis,Dual Slots of power,Without Flexible Card and Power Module, Basic layer 3 Features.
Huawei S5328C-EI-24S switch with 20-ports GE SFP, 4-ports GE combo
With 2 power slots, without power module
With 2 extension slots
Layer 3 Ethernet switch
Forwarding performance: 96Mpps
32K MAC address entries
Non-POE switch
shows the Quick Specs.
Product Code | LS-S5328C-EI-24S |
Fixed Port | 24*10/100 /1000 Base-TX |
Extended slot | two extended slots,which can be installed with uplink subcard and stacking card respectively |
Port switching capacity (bit/s) | 128 Gbit/s |
Board switching capacity | 256 Gbit/s |
Forwarding Performance | 96 Mpps |
RPS | Not supported |
PoE | No |
Mean time between failures (MTBF) | 41.33 years when a 2x10GE card is configured; 50.00 years when a 4xGE front card is configured; 26.52 years when a 4x10GE front card is configured |
Memory | 256 MB |
Flash | 32 MB |
Input voltage | AC: Rated voltage: 100 V to 240 V AC, 50/60 Hz Maximum voltage: 90 to 264 V AC, 50/60 Hz DC: Rated voltage range: –48 V to –60 V, DC Maximum voltage: –36 to –72 V DC Note: POE hosts do not support DC power modules. |
Power consumption | < 60 W |
Dimensions (W x D x H) | 442.0 mm x 420.0 mm x 43.6 mm |
Weight | Fully loaded ≤ 8.5 kg Empty loaded ≤ 5 kg |
shows the recommended elements for the LS-S5328C-EI-24S.
Model | Description |
FE-SFP Optical Transceiver | |
SFP-FE-SX-MM1310 | Optical Transceiver, SFP, 100M/155M, Multi-mode Module(1310nm, 2km, LC) |
eSFP-FE-LX-SM1310 | Optical Transceiver, eSFP, 100M/155M, Single-mode Module(1310nm, 15km, LC) |
S-SFP-FE-LH40-SM1310 | Optical Transceiver, eSFP, FE, Single-mode Module(1310nm, 40km, LC) |
GE-SFP Optical Transceiver | |
eSFP-GE-SX-MM850 | Optical Transceiver, eSFP, GE, Multi-mode Module(850nm, 0.55km, LC) |
SFP-GE-LX-SM1310 | Optical Transceiver, eSFP, GE, Single-mode Module(1310nm, 10km, LC) |
S-SFP-GE-LH40-SM1310 | Optical Transceiver, eSFP, GE, Single-mode Module(1310nm, 40km, LC) |
S-SFP-GE-LH40-SM1550 | Optical Transceiver, eSFP, GE, Single-mode Module(1550nm, 40km, LC) |
10G-SFP+ Optical Transceiver | |
SFP-10G-USR | 10GBase-USR Optical Transceiver, SFP+, 10G, Multi-mode Module(850nm, 0.1km, LC) |
OMXD30000 | Optical Transceiver, SFP+, 10G, Multi-mode Module(850nm, 0.3km, LC) |
OSX010000 | Optical Transceiver, SFP+, 10G, Single-mode Module(1310nm, 10km, LC) |
shows the comparison of LS-S5328C-EI-24S, LS-S5328C-PWR-EI and LS-S5352C-EI.
Product Code | LS-S5328C-EI-24S | LS-S5328C-PWR-EI | LS-S5352C-EI |
Fixed Port | 24*10/100 /1000 Base-TX | 24*10/100 /1000 Base-TX | 48*10/100 /1000 Base-TX |
Port switching capacity (bit/s) | 128 Gbit/s | 128 Gbit/s | 176 Gbit/s |
Board switching capacity | 256 Gbit/s | 256 Gbit/s | 256 Gbit/s |
Forwarding Performance | 96 Mpps | 96 Mpps | 132 Mpps |
RPS | Not supported | Not supported | Not supported |
PoE | No | Yes | No |
Mean time between failures (MTBF) | 41.33 years when a 2x10GE card is configured; 50.00 years when a 4xGE front card is configured; 26.52 years when a 4x10GE front card is configured | 52 years when a 2x10GE card is configured; 55.4 years when a 4xGE front card is configured | 46.05 years when a 2x10GE card is configured; 57.08 years when a 4xGE front card is configured; 25.58 years when a 4x10GE front card is configured |
Memory | 256 MB | 256 MB | 256 MB |
Flash | 32 MB | 32 MB | 32 MB |
Power consumption | < 60 W | Max: 472 W (PoE: 370 W) | < 88 W |
