Detailed Product Description
Products Status: Stock Ports: 24
Transmission Rate: 10/100/1000Mbps Function: LACP, POE, QoS, SNMP, VLAN Support
Communication Mode: Full-Duplex & Half-Duplex Switch Capacity: 128Gbps

S3700 Series Enterprise Switches S3700-28TP-EI-24S-AC  S3700-28TP-EI-AC  S3700-28TP-EI-DC  S3700-28TP-EI  S3700-28TP 0

S3700 Series Enterprise Switches S3700-28TP-EI-24S-AC  S3700-28TP-EI-AC  S3700-28TP-EI-DC  S3700-28TP-EI  S3700-28TP

S3700 Series Enterprise Switches

For Fast Ethernet switching over twisted-pair copper, S3700 Series combines proven reliability with robust routing, security, and management features in a compact, energy-efficient switch.

Flexible VLAN deployment, PoE capabilities, comprehensive routing functions, and capability to migrate to an IPv6 network help enterprise customers build next-generation IT networks.

Choose Standard (SI) models for L2 and basic L3 switching; Enhanced (EI) models support IP multicasting and more complex routing protocols (OSPF, IS-IS, BGP).
S3700 Series Enterprise Switches — products

Specifications

S3700-SI

S3700-EI

Switching Capacity

64 Gbit/s

64 Gbit/s

Forwarding Performance

9.6 Mpps/13.2 Mpps

Port Description

Downlink: 24/48 x 100 Base-TX Ethernet ports

Uplink: 4 x GE ports

Downlink: 24/48 x 100 Base-TX Ethernet ports

Uplink: 4 x GE ports

Reliability

RRPP, Smart Link, and SEP

STP, RSTP, and MSTP

RRPP, Smart Link, and SEP

STP, RSTP, and MSTP

BFD

IP Routing

Static route, RIPv1, RIPv2, and ECMP

Static route, RIPv1, RIPv2, and ECMP

OSPF, IS-IS, and BGP

IPv6 Features

Neighbor Discovery (ND)

Path MTU (PMTU)

IPv6 ping, IPv6 tracert, and IPv6 Telnet

Manually configured tunnel

6to4 tunnel

ISATAP tunnel

ACLs based on the source IPv6 address, destination IPv6 address, Layer 4 ports, or protocol type

MLD v1/v2 snooping

Neighbor Discovery (ND)

Path MTU (PMTU)

IPv6 ping, IPv6 tracert, and IPv6 Telnet

Manually configured tunnel

6to4 tunnel

ISATAP tunnel

ACLs based on the source IPv6 address, destination IPv6 address, Layer 4 ports, or protocol type

MLD v1/v2 snooping

Multicast

1K multicast groups

IGMP v1/v2/v3 snooping and IGMP fast leave

Multicast VLAN and multicast replication between VLANs

Multicast load balancing among member ports of a trunk

Controllable multicast

Port-based multicast traffic statistics

1K multicast groups

IGMP v1/v2/v3 snooping and IGMP fast leave

Multicast VLAN and multicast replication between VLANs

Multicast load balancing among member ports of a trunk

Controllable multicast

Port-based multicast traffic statistics

QoS/ACL

Rate limiting on packets sent and received by an interface

Packet redirection

Port-based traffic policing and two-rate three-color CAR

Eight queues on each port

WRR, DRR, SP, WRR + SP, and DRR + SP queue scheduling algorithms

Re-marking of the 802.1p priority and DSCP priority

Packet filtering on Layers 2 through 4, filtering out invalid frames based on the source MAC address, destination MAC address, source IP address, destination IP address, port number, protocol type, and VLAN ID

Rate limiting in each queue and traffic shaping on ports

Rate limiting on packets sent and received by an interface

Packet redirection

Port-based traffic policing and two-rate three-color CAR

Eight queues on each port

WRR, DRR, SP, WRR + SP, and DRR + SP queue scheduling algorithms

Re-marking of the 802.1p priority and DSCP priority

Packet filtering on Layers 2 through 4, filtering out invalid frames based on the source MAC address, destination MAC address, source IP address, destination IP address, port number, protocol type, and VLAN ID

Rate limiting in each queue and traffic shaping on ports

Security and Access

User privilege management and password protection

DoS attack defense, ARP attack defense, and ICMP attack defense

Binding of the IP address, MAC address, interface, and VLAN

Port isolation, port security, and sticky MAC

Blackhole MAC address entries

Limit on the number of learned MAC addresses

802.1x authentication and limit on the number of users on an interface

AAA authentication, RADIUS authentication, HWTACACS authentication, and NAC

SSH v2.0

CPU defense

Blacklist and whitelist

DHCP server, DHCP relay, DHCP snooping, and DHCP security

User privilege management and password protection

DoS attack defense, ARP attack defense, and ICMP attack defense

Binding of the IP address, MAC address, interface, and VLAN

Port isolation, port security, and sticky MAC

Blackhole MAC address entries

Limit on the number of learned MAC addresses

802.1x authentication and limit on the number of users on an interface

AAA authentication, RADIUS authentication, HWTACACS authentication, and NAC

SSH v2.0

CPU defense

Blacklist and whitelist

DHCP server, DHCP relay, DHCP snooping, and DHCP security

Surge Protection

Surge protection capability of service ports: 7 kV

Surge protection capability of service ports: 7 kV

Management and Maintenance

iStack

MAC Forced Forwarding (MFF)

Remote configuration and maintenance using Telnet

Auto-Config

Virtual cable test

Ethernet OAM (IEEE 802.3ah and 802.1ag)

SNMP v1/v2c/v3 and RMON

MUX VLAN and GVRP

eSight and web NMS

SSH v2

iStack

MAC Forced Forwarding (MFF)

Remote configuration and maintenance using Telnet

Auto-Config

Virtual cable test

Ethernet OAM (IEEE 802.3ah and 802.1ag)

SNMP v1/v2c/v3 and RMON

MUX VLAN and GVRP

eSight and web NMS

SSH v2

Power Consumption

S3700-28TP-SI < 20W

S3700-52P-SI < 38W

S3700-28TP-EI < 20W

S3700-28TP-EI-24S < 52W

S3700-52P-EI < 38W

S3700-28TP-PWR-EI < 818W (PoE: 740W)

S3700-52P-PWR-EI < 880W (PoE: 740W)

Interoperability

Link-type Negotiation Protocol (LNP) (similar to DTP)

VLAN Central Management Protocol (VCMP) (similar to VTP)
