Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | TN11MR2 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| TN11MR2: | 2-channel Optical Add/drop Multiplexing Unit |
|---|
The MR2 board is mainly used to add/drop and multiplex signals, to query wavelengths, and to provide a cascading interface.
For detailed functions and features, refer to Table 1.
| Function and Feature | Description |
|---|---|
| Basic function | Adds/drops and multiplexes two random channels of signals to/from the multiplexed signals. |
| WDM specification | Supports the DWDM specifications. |
| Cascading interface | Provides the interface to cascade another optical add and drop multiplexing board to achieve expansion. |
| Wavelength query | Queries the wavelengths for the added or dropped signals. |
| Optical-layer ASON | Supported. |
Specifications include optical specifications, dimensions, weight, and power consumption.
Table 1 lists the optical specifications of the MR2 board.
| Corresponding interfaces | Item | Unit | Value |
|---|---|---|---|
| - | Operating wavelength range | nm | 1529-1561 |
| - | Adjacent channel spacing | GHz | 100 |
| IN-D1 IN-D2 | -1dB spectral width | nm | >= 0.2 |
| Drop channel insertion loss | dB | <= 1.5 | |
| Adjacent channel isolation | dB | > 25 | |
| Non-adjacent channel isolation | dB | > 35 | |
| A1-OUT A2-OUT | -1dB spectral width | nm | >= 0.2 |
| Add channel insertion loss | dB | <= 1.5 | |
| IN-MO MI-OUT | Insertion loss | dB | <= 1.0 |
| Isolation | dB | > 13 | |
| - | Polarization dependence loss | dB | < 0.2 |
| - | Maximum reflectance | dB | -40 |
The MR2 adds/drops and multiplexes random two channels of signals to/from the multiplexed signals. There are no rules for adding/dropping wavelengths.
The mechanical specifications of TN11MR2 are as follows:
| Board | Typical Power Consumption (W) | Maximum Power Consumptiona (W) |
|---|---|---|
| TN11MR2 | 0.2 | 0.3 |
| a: The maximum power consumption is the power consumed by the board when it works normally under the highest ambient temperature. | ||
