Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | TN52ND2T04 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| TN52ND2T04: | 800 Ps/nm-C Band-Tunable Wavelength-(D)RZ-PIN | Port: | Shenzhen |
|---|
The ND2 board is used at an electrical REG station to electrically regenerate optical signals.
Table 1 describes the functions and features of the ND2 board.
| Function and feature | Description | |
|---|---|---|
| Basic function | Electrically regenerates two optical signals at an electrical REG station. | |
| Supported service rate | OTU2: OTN service at a rate of 10.71 Gbit/s OTU2e: OTN service at a rate of 11.1 Gbit/s or 11.3Gbit/s | |
| OTN functions |
| |
| WDM specification | Supports ITU-T G.694.1-compliant DWDM specifications. | |
| Tunable wavelength function | Supports tunable wavelength optical modules that provide for:
| |
| ESC function | Supported | |
| PRBS test function | Not supported | |
| FEC coding |
NOTE: Boards that use different FEC modes cannot interconnect with each other. | |
| Alarms and performance events monitoring |
| |
| ALS function | Not supported | |
| Test frame | Not supported | |
| Physical clock | Not supported | |
| Protection scheme | Not supported | |
| Loopback | Not supported | |
| Protocols or standards compliance | Protocols or standards for transparent transmission (non-performance monitoring) | - |
| Protocols or standards for service processing (performance monitoring) | ITU-T G.805 ITU-T G.806 ITU-T G.709 ITU-T G.872 ITU-T G.7710 ITU-T G.798 ITU-T G.874 ITU-T M.3100 ITU-T G.874.1 ITU-T G.875 ITU-T G.808.1 ITU-T G.841 ITU-T G.8201 ITU-T G.694.1 | |
| Board | WDM-Side Optical Module | Typical Power Consumption (W) | Maximum Power Consumptiona (W) |
|---|---|---|---|
| TN52ND2 | 800 ps/nm-C Band-Tunable Wavelength-NRZ-PIN | 70.5 | 77.5 |
| 800 ps/nm-C Band-Tunable Wavelength-(D)RZ-PIN | TN52ND2T01: 67.8 TN52ND2T04: 35 | TN52ND2T01: 74.6 TN52ND2T04: 37 | |
| a: The maximum power consumption is the power consumed by the board when it works normally under the highest ambient temperature. | |||
