Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | TNU1NP400E |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| TNU1NP400E: | 1 X 200G Turbo WDM Line Service Processing Extended Board |
|---|
The NP400/NP400E provides functions and features such as OTN interfaces and ESC.
| Function and Feature | Description | ||||||
|---|---|---|---|---|---|---|---|
| Basic function | NP400/NP400E:
| ||||||
| Cross-connect capabilities | Supports the cross-connection of 160 channels of ODU0/ODUflex signals or 80 channels of ODU1 signals or twenty channels of ODU2/ODU2e signals or four channels of ODU3 signals or two channel of ODU4 signals between the NP400/NP400E and the cross-connect board. | ||||||
| OTN function |
| ||||||
| WDM specification | Supports ITU-T G.694.1-compliant DWDM specifications. | ||||||
| ESC function | Supported | ||||||
| PRBS test function | Supports the PRBS function on the WDM side. | ||||||
| LPT function | Not supported | ||||||
| FEC coding | SDFEC NOTE: Boards that use different FEC modes cannot interconnect with each other. | ||||||
| Alarms and performance events monitoring |
| ||||||
| IEEE 1588v2 | Supports the BC, OC modes. | ||||||
| Physical clock | Supported | ||||||
| Optical-layer ASON | Not supported | ||||||
| Electrical-layer ASON | Supported NOTE: When both NP400 and NP400E boards are configured on a network, the ODUk TE links of electrical-layer ASON must be configured to the same SRLG (Shared Risk Link Group). | ||||||
| Protection scheme |
NOTE: The optical line protection is not supported. | ||||||
| Loopback | WDM side Loopback | ODU0 Channel Loopback | ODU1 Channel Loopback | ODU2 Channel Loopback | ODU3 Channel Loopback | ODU4 Channel Loopback | ODUflex Channel Loopback |
| Supported | Supported | Supported | Supported | Supported | Supported | Supported | |
| Protocol or standard compliance | Protocols or standards (non-performance monitoring) with which transparently transmitted services comply | - | |||||
| Protocols or standards (performance monitoring) for processing services | ITU-T G.805 ITU-T G.806 ITU-T G.709 ITU-T G.872 ITU-T G.7710 ITU-T G.798 ITU-T G.874 ITU-T M.3100 ITU-T G.874.1 ITU-T G.875 ITU-T G.808.1 ITU-T G.841 ITU-T G.8201 ITU-T G.694.1 | ||||||
| Board | Typical Power Consumption (W) | Maximum Power Consumptiona (W) |
|---|---|---|
| NP400/NP400E | 250 | 265 |
| a: The maximum power consumption is the power consumed by the board when it works normally under the highest ambient temperature. | ||
