Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | TN52UXCH |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| TN52UXCH: | 3.2T Universal Cross Connect Board | Port: | Shenzhen |
|---|
The UXCH board is mainly used to cross-connect services at the electrical layer.
For detailed functions and features, refer to Table 1.
| Function and Feature | Description |
|---|---|
| Basic function | Implements grooming of services. |
| Cross-connect function | Enhanced OptiX OSN 8800 T32 subrack:
General OptiX OSN 8800 T32 subrack:
|
| Protection scheme |
|
| Switching mode | Supports the manual switching and auto switching. Supports the non-revertive switching. |
| Electrical-layer ASON | Supported |
Specifications include dimensions, weight, and power consumption.
| Board | Power Consumption at Warm Backup (Room Temperature) (W) | Power Consumption at Warm Backup (High Temperature)a (W) | Typical Power Consumption at Room Temperature (W) | Maximum Power Consumptiona(W) |
|---|---|---|---|---|
| TN52UXCH | 87 | 96 | 340 - 7.4 x (32 - n) | 374 - 8.1 x (32 - n) |
a: The maximum power consumption is the power consumed by the board when it works normally under the highest ambient temperature. NOTE: "n" is equal to the total number of tributary, line, and PID boards housed in a subrack. | ||||
