Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | TN11CMR4 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| TN11CMR4: | CWDM 4-channel Optical Add/drop Multiplexing Unit |
|---|
The CMR4 board adds/drops and multiplexes signals, queries wavelengths, and provides a cascading interface.
For detailed functions and features, refer to Table 1.
| Function and Feature | Description |
|---|---|
| Basic function | Adds/Drops and multiplexes four channels of signals to/from the multiplexed signals. |
| WDM specification | Supports the CWDM specifications. |
| Cascading interface | Provides the interface to cascade another optical add and drop multiplexing board to achieve expansion. |
| Wavelength query | Queries the wavelengths for the added or dropped signals. |
| Optical-layer ASON | Not supported |
Specifications include optical specifications, dimensions, weight, and power consumption.
Table 1 lists the optical specifications of the CMR4 board.
| Corresponding interfaces | Item | Unit | Value |
|---|---|---|---|
| - | Operating wavelength range | nm | 1271-1611 (1371 nm excluded) |
| - | Adjacent channel spacing | nm | 20 |
| IN-D1 IN-D2 IN-D3 IN-D4 | 0.5 dB spectral width | nm | >= ±6.5 |
| Drop channel insertion loss | dB | <= 2 | |
| Adjacent channel isolation | dB | > 25 | |
| Non-adjacent channel isolation | dB | > 35 | |
| A1-OUT A2-OUT A3-OUT A4-OUT | 0.5 dB spectral width | nm | >= ±6.5 |
| Add channel insertion loss | dB | <= 2 | |
| IN-MO MI-OUT | Insertion loss | dB | <= 1.5 |
| Isolation | dB | >= 13 | |
| - | Maximum reflectance | dB | -40 |
The equipment can transmit the 1291 nm wavelength by connecting the CMR4 board to corresponding third-party equipment, though the equipment does not provide the 1291 nm OTU board and line board.
The CMR4 board adds/drops and multiplexes four channels of signals to/from the multiplexed signals. There are four wavelength groups.
| Group | Wavelength (nm) | |||
|---|---|---|---|---|
| A1/D1 | A2/D2 | A3/D3 | A4/D4 | |
| 1 | 1291 | 1311 | 1331 | 1351 |
| 2 | 1391 | 1411 | 1431 | 1451 |
| 3 | 1471 | 1491 | 1591 | 1611 |
| 4 | 1511 | 1531 | 1551 | 1571 |
The mechanical specifications of TN11CMR4 board are as follows:
The mechanical specifications of TN21CMR4 board are as follows:
| Board | Typical Power Consumption (W) | Maximum Power Consumptiona (W) |
|---|---|---|
| TN11CMR4/TN21CMR4 | 0.2 | 0.3 |
| a: The maximum power consumption is the power consumed by the board when it works normally under the highest ambient temperature. | ||
