Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | TN11BMD8 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| TN11BMD8: | PID Interleaver Board (C_Band), 200/50 GHz |
|---|
The BMD8 provides functions and features such as multiplexing, demultiplexing, and in-service spectrum detection.
| Function or Feature | Description |
|---|---|
| Basic function | In an 80-channel system, the BMD8 board multiplexes and demultiplexes optical signals. Demultiplexes one channel of input 80-wavelength multiplexed signals with a spacing of 50 GHz into four channels of odd-wavelength signals and four channels of even-wavelength multiplexed signals with a spacing of 200 GHz, that is, four channels of 12-wavelength multiplexed signals and four channels of 8-wavelength multiplexed signals. The reverse process is similar. |
| Detection and monitoring of the online spectrum | Provides an in-service monitoring interface. A small number of optical signals can be output to the spectrum analyzer or spectrum analyzer unit through the interface to monitor the spectrum and optical performance of the multichannel signals without interrupting the services. |
| Optical-layer ASON | Not supported |
The specifications include the optical specifications, dimensions, weight, and power consumption.
| Item | Unit | Value | |
|---|---|---|---|
| Operating wavelength range | nm | 1529 - 1561 | |
| T0x/R0x channel spacinga | GHz | 200 | |
| IN/OUT channel spacing | GHz | 50 | |
| Insertion loss | IN-T01 IN-T02 IN-T03 IN-T04 IN-T05 IN-T06 IN-T07 IN-T08 | dB | <= 8 |
| R01-OUT R02-OUT R03-OUT R04-OUT R05-OUT R06-OUT R07-OUT R08-OUT | dB | <= 9.5 | |
| Isolationb | IN->T01/T05 @T02/T06/T03/T07/T04/T08 IN->T02/T06 @T01/T05/T03/T07/T04/T08 IN->T03/T07 @T01/T05/T02/T06/T04/T08 IN->T04/T08 @T01/T05/T02/T06/T03/T07 | dB | >= 25 |
| IN->T01@T05 IN->T05@T01 IN->T02@T06 IN->T06@T02 IN->T03@T07 IN->T07@T03 IN->T04@T08 IN->T08@T04 | >= 13 | ||
| R01->OUT@R05 R05->OUT@R01 R02->OUT@R06 R06->OUT@R02 R03->OUT@R07 R07->OUT@R03 R04->OUT@R08 R08->OUT@R04 | |||
| Optical return loss | dB | >= 40 | |
| Directivity | dB | >= 45 | |
| PMD | ps | <= 0.5 | |
| Polarization dependent loss | dB | <= 0.5 | |
| Input optical power range | dBm | <= 23 | |
| a: T0x represents T01 to T08 ports. R0x represents R01 to R08 ports. b: In the case of T01/T05@T02/T06/T03/T07/T04/T08, this parameter refers to the isolation between any one of T01/T05 ports and any one of T02/T06/T03/T07/T04/T08 ports. It is the same case for other isolation item. T01 to T04 ports are intended for blue band signals; the T05 to T08 ports are intended for red band signals. | |||
| Board | Typical Power Consumption (W) | Maximum Power Consumptiona (W) |
|---|---|---|
| TN11BMD8 | 0.2 | 0.3 |
| a: The maximum power consumption is the power consumed by the board when it works normally under the highest ambient temperature. | ||
