Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | ZTE ZXCTN 6110 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Type: | Fiber Identifier | Number Name: | ZTE FEx4 |
|---|---|---|---|
| Application: | FTTH FTTB FTTX Network | Color: | Metal Chasis |
| Port: | Shenzhen |
ZXCTN 6000 V3.00 New Generation Compact Cartrier-Class Multiservice Packet Transport Networks Access Platform
Because of the growth of the bandwidth demand of 3G/LTE services and the reduction of TCO, bearer networks are required to provide future oriented large capacity multiple service transport with low cost. ZXCTN 6120S, 6150 and 6180 V3.00 is the new generation compact carrier-class multiservice packet transport networks access platform build a high efficient and power saving wireless bearer network, and benefit telecom operators in market extension & service innovation.
Access Platform - ZTE Enterprise
ZXCTN 6000 series product meets the needs of the industry, is committed to building a multiservice intelligent robust network with large capacity, high reliability and high security, comprehensively improves core competitiveness of bearer networks, and helps industry users with market development and service innovation.
| Specifications | ZXCTN 608 | ZXCTN 608P | ZXCTN 6120E | ZXCTN 6120S | ZXCTN 6150 | ZXCTN 6180 |
| Switching Capacity | 6G | 26G | 32G | 66G | 90G | 100G |
| Packet Forwarding Rate | 8.9Mpps | 36.7Mpps | 47.616Mpps | 98.208Mpps | 133.92Mpps | 148.8Mpps |
| Number of Service Slots | NA | NA | NA | 3 | 6/7 | 10 |
| Main Control Redundancy | NA | NA | NA | NA | 1+1 redundancy | 1+1 redundancy |
| Switch Fabric Redundancy | NA | NA | NA | NA | 1+1 redundancy | 1+1 redundancy |
| Service Slots | Support GE, FE and E1 interfaces | Support 10GE, GE and FE interfaces | Support 10GE, GE, FE and E1 interfaces | Support 10GE, GE, FE, STM-1 and E1 interfaces | Support 10GE, GE, FE, STM-1 and E1 interfaces | Support 10GE, GE, FE, STM-1 and E1 interfaces |
| VLAN Features | Support 802.1Q-based VLAN, VLAN translation and QinQ | |||||
| Link Aggregation | Support LAG link aggregation protection | |||||
| Ring Network Protection | Support G.8132 ring network and shared ring network protection | |||||
| Link Protection | Support 1+1 and 1:1 modes | |||||
| MPLS/MPLS VPN | Support LDP and RSVP-TE protocols; support MPLS L2/L3 VPN | |||||
| QOS/ACL | Traffic classification: Support packet classification based on physical interface, VLAN, 802.1p and DSCP. | |||||
| Functions and Features | L2 features: Support Vlan, MAC management, storm suppression, QinQ, port mirroring, ARP, STP/RSTP/MSTP, 802.1x and DHCP relay. | |||||
| Dimension (W*H*D)mm | 330*43.6*220 | 220*276*79.5 | 482.6*45*199 | 482.6*45*199 | 482.6*88.9*199 | 482.6*130.8*199 |
| Height | 1U | NA | 1U | 1U | 2U | 3U |
| Power Supply | DC power supply: -48V | DC power supply: -48V | DC power supply: -48V | DC power supply: -48V | DC power supply: -48V | DC power supply: -48V |
| Max. Power Consumption | 30W | 90W(with POE) | 50W | 115W | 225W | 340W |
| Typical Power Consumption | 25W | 25W | 40W | 70W | 150W | 250W |
| Working Environment | -40 ℃~+65 ℃ | -40 ℃~+65 ℃ | -40 ℃~+65 ℃ | -30 ℃~+60 ℃ | -30 ℃~+60 ℃ | -20 ℃~+55 ℃ |
| Storage Environment | -40 ℃~+70 ℃ | -40 ℃~+70 ℃ | -40 ℃~+70 ℃ | -40 ℃~+70 ℃ | -40 ℃~+70 ℃ | -40 ℃~+70 ℃ |
| Storage Humidity | 5% ~ 95% | 5% ~ 95% | 5% ~ 95% | 5% ~ 95% | 5% ~ 95% | 5% ~ 95% |
MAN and mobile backhaul network integrated solution
ZXCTN 6000 series product can access and transport integrated services, including various types of industry customer services.
ZXCTN 6000 series product supports MPLS L3VPN and MPLS L2VPN functions.
ZXCTN 6000 series product supports MPLS-TP-based L2VPN and L3VPN functions.
ZXCTN 6000 series product supports flexible network deployment such as L2VPN and L3VPN networking.
Return Material Authorization (RMA) Process
Standard Hardware Warranty Policy:
Original new sealed ZTE product: 1 Year
The Support Contacts:
If your ZTE products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
Cargo will be delivered within 1 day after payment arrived. Tracking Number will be offered once delivery done.
Uonel is one of the biggest Network Hardware distributor in china, founded in 2008. We are a global provider of netwotking products with more than 5000 customers.
We provide original new & ZTE & Cisco & Fiberhome & H3C & Ericsson & Alcatel Lucent & Emerson with Routers,Switches,Firewalls,Wireless APs & controllers,OLTs,GPON modems,optical transceivers.we can provide Plenty of Stock, Fast Delivery, Better price, and original guarantee.
Most of our technical engineers has considerable experience in company,we can provide network design&planning,configration,troubleshooting,maintenance and training service in world wide.
Contact Person: Mr. Leo yang
Tel: +86 15684227158
