| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | ZXWM M900 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Transmission Capacity: | 80Gb/s, 320Gb/s, 800Gb/s To 1600Gb/s. | Optical Signals: | POS, GE And ATM Etc |
|---|---|---|---|
| Optical Interfaces: | Open And Integrated | Protection Functions: | Various |
| Multiple Section: | 1+1 Protection | Optical Channel: | 1+1 Protection |
Hong Telecom Equipment Service LTD (HongTelecom) is formal distributor of Huawei, ZTE and Emerson. Our team come from Huawei, ZTE, Emerson, CISCO, Alcatel, Ericsson, Fiberhome mostly. So we have established very good cooperative relationship with Huawei, Ericsson, Nokia, NSN, ZTE, Vertiv, Emerson, Fiberhome, Cisco, Juniper, HPE, DELL, Alcatel-Lucent, Nortel, H3C. We can provide one-stop purchasing platform for our customer with very good price and very fast delivery.
Hong Telecom Equipment Service LTD (HongTelecom) is a leading professional equipment distributor and service provider in telecommunication infrastructure and solution field, and now is extending our business to ICT (Information and Communication Technology) field.
HongTelecom offer full range of telecom infrastructure products, our business scope include Router/Switch/BRAS, GPON/EPON/FTTX, Optical TRANSMISSION(SDH/DWDM/PTN/Microwave), DSLAM/PSTN/MSAG/MSAN, Firewall/Security Gateway, Power Energy/UPS/indoor Outdoor Cabinet, Video Conference, WLAN etc., We also supply used and refurbished wireless and core network, including Huawei/Ericsson/ NSN/Alcatel/ZTE, GSM/UMTS/LTE, BBU, RRU, BTS.
The ZTE ZXMP M900
Super-large-capacity transmission and modular upgrade
When configured as 10G system, 96/192-wavelength system framework is recommended. The subsystem can perform modular capacity expansion, with transmission capacities of 400Gbit/s, 480Gbit/s, 800Gbit/s, 960Gbit/s and even to 1920Gbit/s available;
When configured as 40G system, C band 96-wavelength system framework is recommended. The subsystem can perform modular capacity expansion, with transmission capacities of 1.6T,1.92T, 3.2T, and 3.84T available, addressing tomorrow's escalating bandwidth requirements.
Single-wavelength 40Gbit/s technology
The 40Gbit/s system utilizes ODB, DPSK and RZ-DPQSK modulation formats, which provide better signal-to-noise ratio and enhanced non-linearity. With automatic dispersion compensation (TDC), it is applicable to ultra-long-haul transmission. Furthermore, 40Gbit/s service board employing ODB, DPSK technologies has high slot utilization and lower power consumption.
Ultra-long-haul transmission capability
10G system configuration supports repeaterless transmission over 5000km; 40G system configuration supports repeaterless transmission over 2000km.
Full support of OTN functionality
All line interfaces of ZXWM M900 equipment support OTN standard, OTN overhead detection and utilization, and cross-connect scheduling of ODUk granule, in full compliance with G.709 and G.798 Recommendations; ZXWM M900 supports TCM domain management overhead, enables multi-vendor and multi-domain precise fault localization and message transfer, thus implementing interworking of multi-domain and multi-vendor equipments.
IWF (integrated wavelength feedback) patented technique
Combination of self-patented wavelength centralized monitoring technique and precise temperature control further guarantees the wavelength stability of 50/25GHz wavelength spacing system.
Highly integrated MUX/DMUX with low power consumption
The unique 80-λ MUX/DEMUX architecture allows for multiplexing/demultiplexing of 80 wavelengths without use of OCI, causing slot occupation and power consumption to decrease by 20% and 50% respectively.
Wavelength add/drop function
Designed with flexible MUX/DMUX architecture, ZXWM M900 enables agile add/drop of 1-96/192 wavelengths. It supports fixed optical add/drop multiplexing (FOADM) and reconfigurable optical add/drop multiplexing (ROADM) functions.
Flexible and mature protection schemes
Multiple protection modes are available: 1+1 path protection, 2-fiber bidirectional path shared protection, 2-fber bidirectional multiplex section shared protection, subnet connection protection, 1+1 multiplex section protection and equipment-side 1:N OTU protection. ZTE's innovative path shared protection technique vastly decreases protection wavelengths used, saving network construction cost.
Strong service access and aggregation capability
Aggregate STM-1(OC3), STM-4(OC12), STM-16(OC48), STM-64(OC192), STM-256, FE, GE/10GE, FICON, ESCON, FC, ATM, PDH services into 2/8×GE, 4×155M, 4×622M, 4×2.5G, 4×10G, 8×Any, 2/4/8×FC, etc.
