China Huawei Telecom Equipment manufacturer
Uonel Co.Limtied

Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.

Home ProductsHuawei Wireless Network

Huawei 5100 ERRU3232 ERRU3232b Huawei Wireless Network Frequency Band

Huawei 5100 ERRU3232 ERRU3232b Huawei Wireless Network Frequency Band

  • Huawei 5100 ERRU3232 ERRU3232b Huawei Wireless Network Frequency Band
Huawei 5100 ERRU3232 ERRU3232b Huawei Wireless Network Frequency Band
Product Details:
Place of Origin: China
Brand Name: Huawei
Certification: CE FCC RoHS
Model Number: eRRU3232 eRRU3232b
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Export carton package
Delivery Time: 7-15 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 200 Piece/Pieces per Week
Contact Now
Detailed Product Description
Chipset: Original Application: Wireless Networking Sites
Model: ERRU3232 ERRU3232b Condition: 100% Original Brand
Warranty: 1 Year Weight: 10.5~20.5 Kg
Storage Condition: Consultable
High Light:

ERRU3232b Huawei Wireless Network


Huawei 5100 ERRU3232


Huawei 5100 ERRU3232b

Huawei 5100 Series Remote Radio Units eRRU3232 eRRU3232b Frequency Band


RRU Functions:


The Remote Radio Unit (RRU) consists of the high-speed interface unit, signal processing unit, power amplifier, duplexer,
extension ports, and power module.



The RRU performs the following functions:

* Receives downlink baseband data from the BBU and sends uplink baseband data to the BBU.
* Receives RF signals from the antenna system, down-converts the signals to intermediate frequency (IF) signals, amplifies the IF signals, performs analog-to-digital conversion, and up-converts RF signals to the transmit (TX) band.
* Multiplexes receive (RX) and TX signals on the RF channel so that these signals can share the same antenna channel, and filters the RX and TX signals.
* Provides a built-in Bias Tee (BT). The built-in BT couples RF signals and OOK signals and transmits them through the TX/RX port A. The built-in BT also supplies power to the tower mounted amplifier (TMA).
* The RRU can work with the Monitoring Extension Box (MEB). The MEB can transmit external RS-485 communication signals and dry node monitoring signals into the RRU, implementing information monitoring and reporting.

* When an RRU is equipped with an AC/DC power module, the RRU and the power module together are called an AC RRU.




1. Original Carton Package.
2. As customers' requirement.


1. 3-7 Working days after received the payment.
2. Shipment: Sea transportation & Air transportation ( DHL / UPS / TNT / Fedex / EMS )
