Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | CE8860-4C-EI |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Product Series: | Huawei CE8800 | Product Status: | Stock |
|---|---|---|---|
| Huawei Network SwitchesType: | Huawei Network Switches | Model: | CE8860-4C-EI-B |
| High Light: | Huawei CE8800 Huawei Network Switches,CE8860-4C-EI-B Huawei Network Switches,CE8860-4C-EI |
||
Product Overview
Huawei CloudEngine CE8800 Series Data Center Switches
Huawei CloudEngine 8800 series (CE8800) switches are 100G Ethernet switches designed for data centers and high-end campus networks. The switches provide high-performance, high-density 100 GE/40 GE/25 GE/10 GE ports, and low latency. Using the Huawei VRP8 software platform, CE8800 switches provide extensive data center service features and high stacking capability. In addition, the airflow direction (front-to-back or back-to-front) can be changed. CE8800 switches can work with CE12800/CE8800/CE6800/CE5800 switches to build an elastic, virtualized, high-quality fabric for cloud-computing data centers.
CE8800 switches can function as core or aggregation switches on data center networks to help enterprises and carriers build a scalable data center network platform in the cloud computing era. They can also be used as aggregation or core switches for enterprise campus networks.
Product Details
Product Specifications
CE8860-4C-EI
2U high, supporting four flexible cards of half the standard width
CE8860 supports the following models of cards:
CE8860-4C-EI-B CE8860-4C-EI switch
4 slots with airflow from the front panel (with ports) to the fan module panel, without power module
Ordering information(CE8800)
Ordering Information
1. Mainframe
CE8860-4C-EI-F CE8860-4C-EI switch (4 subcard slots with airflow from the fan module panel to the front panel (with ports and without power module))
CE8860-4C-EI-B CE8860-4C-EI switch (4 slots with airflow from the front panel (with ports) to the fan module panel, without power module)
2. Subcard
CE88-D8CQ 8-port, 100G Ethernet optical (QSFP28)
CE88-D16Q 16-port, 40G Ethernet optical (QSFP+)
CE88-D24T2CQ 24-port, 10G Ethernet electrical (RJ45) and 2-port 100G Ethernet optical (QSFP28)
CE88-D24S2CQ 24-port, 10G Ethernet optical (SFP+) and 2-port 100G Ethernet optical (QSFP28)
3. Fan Box
FAN-180A-F, Fan box (F, FAN panel side intake)
FAN-180A-B, Fan box (B, FAN panel side exhaust)
4. Power Supply
PAC-1K2WA-F 1,200W AC and 240V DC power module with airflow from the power module panel to the front panel (with ports)
PAC-1K2WA-B 1,200W AC and 240V DC power module, with airflow from the front panel (with ports) to the power module panel
PHD-1K2WA-F 1,200W high-voltage DC power module with airflow from the power module panel to the front panel (with ports)
PHD-1K2WA-B 1,200W high-voltage DC power module with airflow from the front panel (with ports) to the power module panel
5. Software
CE88-LIC-NPV, CloudEngine 8800 FCoE NPV Function
CE88-LIC-FCF16, CloudEngine 8800 FCF 16 Ports
CE88-LIC-FCFAL, CloudEngine 8800 FCF All Ports
CE88-LIC-VXLAN, CloudEngine 8800 VXLAN Function
