Huawei AR100 Series Enterprise Huawei Ar109 Router 4 X GE LAN 40 Mbit/s

Huawei AR100 Series Enterprise Huawei Ar109 Router 4 X GE LAN 40 Mbit/s

  • Huawei AR100 Series Enterprise Huawei Ar109 Router 4 X GE LAN 40 Mbit/s
  • Huawei AR100 Series Enterprise Huawei Ar109 Router 4 X GE LAN 40 Mbit/s
  • Huawei AR100 Series Enterprise Huawei Ar109 Router 4 X GE LAN 40 Mbit/s
  • Huawei AR100 Series Enterprise Huawei Ar109 Router 4 X GE LAN 40 Mbit/s
Huawei AR100 Series Enterprise Huawei Ar109 Router 4 X GE LAN 40 Mbit/s
Product Details:
Place of Origin: China
Brand Name: Huawei
Certification: CE FCC RoHS
Model Number: AR109
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Export carton package
Delivery Time: 7-15 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 200 Piece/Pieces per Week
Contact Now
Detailed Product Description
Product Series: AR100 Product Status: Stock
WAN Speed With Services (IMIX): 40 Mbit/s Dimensions: 30 Mm X 230 Mm X 130 Mm
Fixed Ports: 4 X GE LAN, 1 X VDSL2/ADSL, 1 X GE WAN
High Light:

40 Mbit/S Huawei Ar109 Router

,

4 X GE Huawei Ar109 Router

,

4 X GE huawei ar100 series

Huawei AR100 Series Enterprise Router Huawei AR109

Huawei's next-generation routers, the AR100, AR120, AR150, AR160, and AR200 series are designed for enterprise branch offices and small businesses, delivering a comprehensive set of services, including routing, switching, voice, security, and wireless access.



The AR100, AR120, AR150, AR160, and AR200 series are fixed interface routers that provide a comprehensive platform for a variety of network topologies, including IMS, NGN, WAN, and PSTN. The AR100, AR120, AR150, AR160, and AR200 also employ embedded hardware encryption for security as well as a voice Digital Signal Processor (DSP) for voice services.

The AR100, AR120, AR150, AR160, and AR200 series are mature, stable, quiet routers that offer high performance functionality for small networks, enabling small businesses to greatly increase productivity at a lower cost.

AR100s, AR120s, AR150s, AR160s, and AR200s are easy to deploy, configure and customize, greatly reducing cost of deployment and maintenance, while offering maximum value to customers. These models allow network administrators to expand their networks easily and quickly, saving time and costs. Both models support firewalls, call processing, and application program functionalities.

The AR100, AR120, AR150, AR160, and AR200 series includes the following models:

1. AR109, AR109W, AR109GW-L
2. AR129CGVW-L, AR121, AR121W, AR129, and AR129W
3. AR151, AR151G-HSPA+7, AR156, AR156W, AR157, AR157G-HSPA+7, AR157VW, AR157W, AR158E, and AR158EVW
4. AR161, AR161F, AR161FG-L, AR161FGW-L, AR161FW, AR161G-L, AR161W, AR161FV-1P, AR162F, AR168F, AR169, AR169F, AR169FVW, AR169FGW-L, AR169FGVW-L, AR169G-L, and AR169W

5. AR201, AR207, AR207G-HSPA+7 and AR208E

Product Details

AR100 models

Model
Description
AR190
WAN speed with services (IMIX): 40 Mbit/s
Fixed ports: 4 x GE LAN, 1 x VDSL2/ADSL, 1 x GE WAN
Dimensions (H x W x D): 30 mm x 230 mm x 130 mm (1.18 in. x 9.1 in. x 5.1 in.)
AR109W
WAN speed with services (IMIX): 40 Mbit/s
Fixed ports: 4 x GE LAN, 1 x VDSL2/ADSL, 1 x GE WAN
WLAN: 802.11b/g/n
Dimensions (H x W x D): 30 mm x 230 mm x 130 mm (1.18 in. x 9.1 in. x 5.1 in.)
AR109GW-L
WAN speed with services (IMIX): 40 Mbit/s
Fixed ports: 4 x GE LAN, 1 x VDSL2/ADSL, 1 x GE WAN
LTE: LTE FDD
WLAN: 802.11b/g/n
Dimensions (H x W x D): 30 mm x 230 mm x 130 mm (1.18 in. x 9.1 in. x 5.1 in.)

AR120 models

Model
Description
AR129CGVW-L
WAN speed with services (IMIX): 50 Mbit/s
Fixed ports: 4 x GE LAN, 1 x VDSL, 1 x GE WAN
Voice ports: 2 x FXS
LTE: LTE FDD
WLAN: 802.11ac, 802.11b/g/n
Dimensions (H x W x D): 30 mm x 230 mm x 130 mm (1.18 in. x 9.1 in. x 5.1 in.)
AR121
WAN speed with services (IMIX): 50 Mbit/s
Fixed ports: 4 x FE LAN (can be configured as WAN interfaces), 1 x FE WAN
Dimensions (H x W x D): 1.75 in. x 11.8 in. x 8.66 in. (44.5 mm x 300 mm x 220 mm)
AR121W
WAN speed with services (IMIX): 50 Mbit/s
Fixed ports: 4 x FE LAN (can be configured as WAN interfaces), 1 x FE WAN, and 802.11b/g/n
Dimensions (H x W x D): 44.5 mm x 300 mm x 220 mm (1.75 in. x 11.8 in. x 8.66 in.)
AR129
WAN speed with services (IMIX): 50 Mbit/s
Fixed ports: 4 x FE LAN (can be configured as WAN interfaces), 1 x VDSL2 WAN
Dimensions (H x W x D): 1.75 in. x 11.8 in. x 8.66 in. (44.5 mm x 300 mm x 220 mm)
AR129W
WAN speed with services (IMIX): 50 Mbit/s
Fixed ports: 4 x FE LAN (can be configured as WAN interfaces), 1 x VDSL2 WAN, and 802.11b/g/n
Dimensions (H x W x D): 44.5 mm x 300 mm x 220 mm (1.75 in. x 11.8 in. x 8.66 in.)

AR150 models



AR151
WAN speed with services (IMIX): 100 Mbit/s
Fixed ports: 4 x FE LAN (can be configured as WAN interfaces), 1 x FE WAN
Dimensions (H x W x D): 1.75 in. x 11.8 in. x 8.66 in. (44.5 mm x 300 mm x 220 mm)
AR151G-HSPA+7
WAN speed with services (IMIX): 100 Mbit/s
Fixed ports: 4 x FE LAN (can be configured as WAN interfaces), 1 x FE WAN, and WCDMA HSPA+7
Dimensions (H x W x D): 1.75 in. x 11.8 in. x 8.66 in. (44.5 mm x 300 mm x 220 mm)
AR156
WAN speed with services (IMIX): 100 Mbit/s
Fixed ports: 4 x FE LAN (can be configured as WAN interfaces), 1 x ADSL2+ Annex J
Dimensions (H x W x D): 1.75 in. x 11.8 in. x 8.66 in. (44.5 mm x 300 mm x 220 mm)
AR156W
WAN speed with services (IMIX): 100 Mbit/s
Fixed ports: 4 x FE LAN (can be configured as WAN interfaces), 1 x ADSL2+ Annex J, and 802.11b/g/n
Dimensions (H x W x D): 1.75 in. x 11.8 in. x 8.66 in. (44.5 mm x 300 mm x 220 mm)
AR157
WAN speed with services (IMIX): 100 Mbit/s
Fixed ports: 4 x FE LAN (can be configured as WAN interfaces), 1 x ADSL2+ Annex A/M
Dimensions (H x W x D): 1.75 in. x 11.8 in. x 8.66 in. (44.5 mm x 300 mm x 220 mm)
AR157G-HSPA+7
WAN speed with services (IMIX): 100 Mbit/s
Fixed ports: 4 x FE LAN (can be configured as WAN interfaces), 1 x ADSL2+ Annex A/M, and WCDMA HSPA+7
Dimensions (H x W x D): 1.75 in. x 11.8 in. x 8.66 in. (44.5 mm x 300 mm x 220 mm)
AR157VW
WAN speed with services (IMIX): 100 Mbit/s
Fixed ports: 4 x FE LAN (can be configured as WAN interfaces), 1 x ADSL2+ Annex A/M, and 802.11b/g/n
Fixed Voice ports: 4 x FXS, 1 x FXO
Dimensions (H x W x D): 1.75 in. x 11.8 in. x 8.66 in. (44.5 mm x 300 mm x 220 mm)
AR157W
WAN speed with services (IMIX): 100 Mbit/s
Fixed ports: 4 x FE LAN (can be configured as WAN interfaces), 1 x ADSL2+ Annex A/M, and 802.11b/g/n
Dimensions (H x W x D): 1.75 in. x 11.8 in. x 8.66 in. (44.5 mm x 300 mm x 220 mm)
AR158E
WAN speed with services (IMIX): 100 Mbit/s
Fixed ports: 4 x FE LAN (can be configured as WAN interfaces), 1 x G.SHDSL 4-pair
Dimensions (H x W x D): 1.75 in. x 11.8 in. x 8.66 in. (44.5 mm x 300 mm x 220 mm)
AR158EVW
WAN speed with services (IMIX): 100 Mbit/s
Fixed ports: 4 x FE LAN (can be configured as WAN interfaces), 1 x G.SHDSL 4-pair, and 802.11b/g/n
Fixed Voice ports: 4 x FXS, 1 x FXO
Dimensions (H x W x D): 1.75 in. x 11.8 in. x 8.66 in. (44.5 mm x 300 mm x 220 mm)

AR200 models

Model
Description
AR201
WAN speed with services (IMIX): 150 Mbit/s
Fixed ports: 8 x FE LAN (can be configured as WAN interfaces), 1 x FE WAN
Dimensions (H x W x D): 1.75 in. x 11.8 in. x 8.66 in. (44.5 mm x 300 mm x 220 mm)
AR207
WAN speed with services (IMIX): 150 Mbit/s
Fixed ports: 8 x FE LAN (can be configured as WAN interfaces), 1 x ADSL2+ Annex A/M
Dimensions (H x W x D): 1.75 in. x 11.8 in. x 8.66 in. (44.5 mm x 300 mm x 220 mm)
AR207G-HSPA+7
WAN speed with services (IMIX): 150 Mbit/s
Fixed ports: 8 x FE LAN (can be configured as WAN interfaces), WCDMA HSPA+7, and 1 x ADSL2+ Annex A/M
Dimensions (H x W x D): 1.75 in. x 11.8 in. x 8.66 in. (44.5 mm x 300 mm x 220 mm)
AR208E
WAN speed with services (IMIX): 150 Mbit/s
Fixed ports: 8 x FE LAN (can be configured as WAN interfaces), 1 x G.SHDSL 4-pair
Dimensions (H x W x D): 1.75 in. x 11.8 in. x 8.66 in. (44.5 mm x 300 mm x 220 mm)


Product characteristics

★ 1. Small size and high performance

★ 2. Low investment with high returns

★ 3. Small footprint on a comprehensive platform
