Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| With Modem Function: | Yes | Standards And Protocols: | Wi-Fi 802.11g |
|---|---|---|---|
| Encryption Type: | WPA2-PSK | Products Status: | New, Stock |
| Type: | Routers | Application: | ENTERPRISE |
| Function: | Router, Router | LAN Ports: | 8 |
| WAN Ports: | 2 | Color: | Black |
| Port: | ShenZhen Or HongKong |
The EX3200 line of fixed-configuration switches from Juniper Networks® offer a highperformance standalone solution for access-layer deployments in branch and remote offices as well as campus networks. Featuring complete Layer 2 and Layer 3 switching capabilities, the EX3200 satisfies the wiring closet connectivity requirements of today’s high-performance businesses. Four platform configurations are available offering 24 and 48 10/100/1000BASE-T ports with either full or partial Power over Ethernet (PoE). The base 24- and 48-port EX3200 switches deliver up to 18.6 watts of Class 3 PoE on the first eight ports for supporting networked devices such as telephones, video cameras and wireless LAN (WLAN) access points in converged networks. The EX3200 switches with full PoE deliver up to 18.6 watts on all 24 or 48 ports to support high-density IP telephony and other converged network environments. The EX3200 also supports optional four-port Gigabit Ethernet (GbE) and two-port 10 GbE uplink modules with pluggable optics to provide high-speed connectivity to aggregationlayer switches or other upstream devices. A field-replaceable power supply and fan tray minimize mean time to repair (MTTR) for the EX3200, ensuring maximum availability.
Six EX3200 models are available (see Table 1 below)
| Model | Access Port Configuration | PoE Ports | Height | POE Budget | Power Supply Rating |
| EX3200-24T | 24-port 10/100/1000BASE-T | 8 | 1RU | 130 W | 320 W AC |
| EX3200-24P | 24-port 10/100/1000BASE-T | 24 | 1RU | 410 W | 600 W AC |
| EX3200-48T | 48-port 10/100/1000BASE-T | 8 | 1RU | 130 W | 320 W AC |
| EX3200-48P | 48-port 10/100/1000BASE-T | 48 | 1RU | 740 W | 930 W AC |
| EX3200-24T-DC | 24-port 10/100/1000BASE-T | 0 | 1RU | N/A | 190 W AC |
| EX3200-48T-DC | 48-port 10/100/1000BASE-T | 0 | 1RU | N/A | 190 W AC |
All PoE ports 802.3af-compliant @ 15.4 W
EX3200 Specifications
DRAM – 512 MB
Flash – 1 GB
CPU – 600 MHz PowerPC CPU • GbE port density per system
24P/24T: 24 (24 host ports or 20 host ports + four-port GbE uplink module)
10 GbE port density per system (all models): 2 (XFP or SFP+ uplink module)
Optics
100 Mbps optic/connector type: LC SFP fiber supporting 100BASEFX SFP (multimode), LX (single-mode) and BX (single-strand)
10/100/1000BASE-T connector type: RJ-45
GbE SFP optic/connector type: RJ-45 or LC SFP fiber supporting 1000BASE-T SFP, SX (multimode), LX (single-mode) or LH/ZX (single-mode)
10 GbE XFP optic/connector type: 10GE XFP LC connector, SR (multimode), LR (single-mode), ER (single-mode) or ZR (single-mode)
10 GbE SFP+ optic/connector type: 10GE SFP+ LC connector, SR (multimode), USR (multimode), LR (single-mode), ER (singlemode), LRM (multimode) and DAC (direct-attach copper) Physical Layer
Physical port redundancy: Redundant trunk group (RTG)
Time Domain Reflectometry (TDR) for detecting cable breaks and short
Auto MDI/MDIX support
Port speed downshift/setting max advertised speed on 10/100/1000BASE-T ports Packet Switching Capacities (Maximum with 64 Byte Packets)
24P/24T: 88
