CX600 Metro Services Platform CX600-X16A
Physical specifications of the CX600-X16A
| Item | Specification | ||
|---|---|---|---|
| Dimensions (H x W x D) | 1778 mm (40U) x 442 mm x 650 mm (70.00 in. x 17.40 in. x 25.59 in.) (chassis main body dimensions) 1778 mm (40U) x 442 mm x 750 mm (70.00 in. x 17.40 in. x 29.53 in.) (chassis dimensions including the chassis's front and rear assembly and cable racks) | ||
| Installation position | |||
| Weight | Full configuration: 399.4 kg (880.68 lb) (DC) /395.1 kg (871.20 lb) (AC) (Full configuration with 1T interface boards) Full configuration: 356 kg (784.98 lb) (DC) /350.7 kg (773.29 lb) (AC) (Full configuration with 480G interface boards) Empty chassis: 120.5 kg (265.70 lb) (DC)/111.7 kg (246.30 lb) (AC) Integrated chassis with 480G interface boards: 142.1 kg (313.33 lb) (DC)/133.3 kg (293.93 lb) (AC) Integrated chassis with 1T interface boards: 176.4 kg (388.96 lb) (DC) /133.3 kg (293.93 lb) (AC) | ||
| Typical power consumption | 12390 W (Full configuration with 1T boards) 9040 W (Full configuration with 480G boards) | ||
| Heat dissipation | 40198.4 BTU/hour (Full configuration with 1T boards) 29329.6 BTU/hour (Full configuration with 480G boards) | ||
| DC input voltage | Rated voltage | -48 V DC / -60 V DC | |
| Maximum voltage range | -40 V DC to -72 V DC | ||
| AC input voltage | Rated voltage | 200 V AC to 240 V AC(220V) | |
| Maximum voltage range | 180V AC to 264V AC | ||
| System reliability | MTBF (year) | 12.20 | |
| MTTR (hour) | 0.5 | ||
| Ambient temperature | Long-term | 0°C to 40°C(32°F to 104°F) | |
| Short-term | -5°C to 50°C (23°F to 122°F) | ||
| Remarks | Limit of the temperature change rate: 30°C/hour (86°F/hour) | ||
| Storage temperature | -40°C to 70°C (-40°F to 158°F) | ||
| Relative humidity | Long-term | 5% RH to 85% RH, no coagulation | |
| Short-term | 5% RH to 95% RH, no coagulation | ||
| Storage humidity | 5% RH to 95% RH, no coagulation | ||
| Long-term altitude | ≤ 4000 m (13123.2 ft). If the altitude is between 1800 meters (5905.44 ft) and 4000 meters, the maximum operating temperature of the device must decrease by 1°C for every 220 meters (721.776 ft) increase in altitude. | ||
| Storage altitude | Lower than 5000 m (16404 ft.) | ||
System configuration list of the CX600-X16A
| Item | Description | Remarks |
|---|---|---|
| Processing unit | Main frequency: 2.0 GHz | - |
| SDRAM | 16 GB | Two 8GB memory modules |
| SSD card | 8 GB | Two SSD cards can be configured. |
| Switching capacity | 50.32 Tbit/s (LPUI-1T) | - |
| Number of LPU slots | 16 | - |
| Number of MPU slots | 2 | - |
| Number of SFU slots | 4 | - |
