Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| With Modem Function: | Yes | Standards And Protocols: | Wi-Fi 802.11g |
|---|---|---|---|
| Encryption Type: | WPA2-PSK | Products Status: | New, Stock |
| Type: | Wired | Application: | ENTERPRISE |
| Function: | FireWall, QoS, VPN | LAN Ports: | 1 |
| Port: | Shenzhen |
ATN 910B-F DC ANGM01HSDD00 Router
Functions and features of the ATN 910B
| Function and Feature | Description | |
|---|---|---|
| Switching capability | ATN 910B-A: 88 Gbit/s (44 Gbit/s for the upstream traffic and 44 Gbit/s for the downstream traffic) ATN 910B-B: 88 Gbit/s (44 Gbit/s for the upstream traffic and 44 Gbit/s for the downstream traffic) ATN 910B-D: 128 Gbit/s (64 Gbit/s for the upstream traffic and 64 Gbit/s for the downstream traffic) ATN 910B-E: 128 Gbit/s (64 Gbit/s for the upstream traffic and 64 Gbit/s for the downstream traffic) ATN 910B-F: 128 Gbit/s (64 Gbit/s for the upstream traffic and 64 Gbit/s for the downstream traffic) | |
| Auxiliary interface function | Provides one NM serial port or NM network port to communicate with the NMS so that the NMS can manage and query the equipment. | |
| Provides two interfaces for inputting and outputting the external clock/time to obtain the external clock/time information. | ||
| Provides one alarm input/output interface. The interface provides three inputs of alarm digital parameters. | ||
| Provides one 50-ohm clock test interface to output the 1 PPS clock signals (only on the ATN 910B-E). | ||
| Ethernet interface function | The FE/GE SFP interface supports FE optical modules, GE optical modules, and GE electrical modules. The 10GE XFP interface supports 10GE XFP optical modules (only on the ATN 910B-A/ATN 910B-B). The 10GE SFP+ interface supports 10GE SFP+ optical modules (only on the ATN 910B-D/ATN 910B-E/ATN 910B-F). | |
| FE/GE electrical interfaces support signals at 10 Mbit/s, 100 Mbit/s, and 1000 Mbit/s. | ||
| Supports inloops and outloops. | ||
| GE interfaces support flow control. | ||
| Supports Layer 2 and Layer 3 working modes. | ||
| Supports physical-layer clock synchronization (synchronous Ethernet). Supports IEEE 1588v2 and IEEE 1588 ACR. | ||
| E1 interface function (only on the ATN 910B-A) | Supports a 75-ohm or 120-ohm impedance value (based on the actual E1 cable) | |
| Supports the E1 and CE1 modes. | ||
| Supports the master/slave clock mode. | ||
| Supports the HDB3 line coding (unconfigurable). | ||
| Supports inloops and outloops. | ||
| Supports the PRBS function in framed or unframed mode of an E1 interface in the receive/transmit direction. | ||
| Supports the ATM, TDM, and PPP protocols. | ||
