Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| With Modem Function: | Yes | Standards And Protocols: | Wi-Fi 802.11g |
|---|---|---|---|
| Encryption Type: | WPA2-PSK | Products Status: | New, Stock |
| Type: | Wired | Application: | ENTERPRISE |
| Function: | FireWall, QoS, VPN | LAN Ports: | 1 |
| Port: | Shenzhen |
ATN 905 AC ANPM000AIC00
Functions and features of the ATN 905
| Function and Feature | Description | |
|---|---|---|
| Auxiliary interface function | Provides one NM serial port or NM network port to communicate with the NMS so that the NMS can manage and query the equipment. | |
| Provides two interfaces for inputting and outputting the external clock/time to obtain the external clock/time information. (Only the ATN 905 DC supports this function.) | ||
| Provides one alarm input/output interface. The interface provides three inputs of alarm digital parameters. (Only the ATN 905A-P supports this function.) | ||
| Provides one RS485 interface. The interface helps managed external power system. (Only the ATN 905A-D supports this function.) | ||
| Ethernet interface function | FE/GE SFP interfaces support FE optical modules, FE electrical modules, GE optical modules, GE electrical modules, AE 905S modules (supported by the FE/GE2 interface of the ATN 905A), and GPON optical modules (supported by the indoor ATN 905). | |
| FE/GE electrical interfaces support signals at 10 Mbit/s, 100 Mbit/s, and 1000 Mbit/s. | ||
| Supports inloops and outloops. | ||
| GE interfaces support flow control. | ||
| Supports Layer 2 and Layer 3 working modes. | ||
| Supports physical-layer clock synchronization (synchronous Ethernet). Supports IEEE 1588v2 and IEEE 1588 ACR. | ||
| VDSL2 interface function (supported by only the ATN 905-V and ATN 905A-V) | Used on the NNI side. | |
| Compatibility with ADSL2+ (supported by only the ATN 905-V) | ||
| Provides one binding group. | ||
| Supports Vectoring. | ||
| ATN 905A-V | Supports the Annex B protocol mode. | |
| ATN 905-V |
| |
| E1 interface function (supported by only the ATN 905-E) | Supports the E1 and CE1 modes. | |
| Supports the master/slave clock mode. | ||
| Supports the HDB3 line coding (unconfigurable). | ||
| Supports inloops and outloops. | ||
| Supports the PRBS function in framed or unframed mode of an E1 interface in the receive/transmit direction. | ||
| Supports CES services in CESoPSN and SAToP modes. | ||
Appearance of an indoor ATN 905 AC device
